Tier 1 Solar Panels 600W 560W 550W 540W 500W Mono Solar Panels 700 Watt 685W 650W 610W Ground Roof Solar Panel Bracket N Panel Solar Panel
Overview Product Description Solar Cell > High-efficiency MBB PV cell> Uniform color> Anti-PID> Germany standard Cell> F
Description
Basic Info
| Model NO. | GS60M-590-610 |
| After-sales Service | 25years |
| Warranty | 25 Years |
| Number of Cells | 60PCS |
| Application | Light Industry |
| Condition | New |
| Certification | ISO, CE, TUV |
| Material | Monocrystalline Silicon |
| Solar Cell | 120X60mm |
| Power | 590W-610W |
| Glass | 3.2mm Tempered Low Iron |
| Weight | 33kg |
| Connector | Mc4 Compatible Connector |
| Feature | High Efficiency Mono Solar Panel |
| Transport Package | 31 Pieces Panels Packed in a Pallet |
| Specification | 2172*1303*35mm |
| Trademark | Giftsun |
| Origin | China |
| Production Capacity | 5000000watt Per Month |
Product Description
Product Description
| Electrical Parameters | |
| Module | GS610M-120 |
| Encapsulation | Class/Eva/Cell/Eva/Backsheet |
| Maximum Power Pmax(W) | 610 |
| Maximum Power Voltage(Vmp/V) | 37.80 |
| Maximum Power Current(Imp/A) | 17.20 |
| Open Circuit Voltage(Voc/V) | 45.20 |
| Short Circuit Currrnt(Isc/A) | 18.26 |
| Module Efficiency(%) | 20.90 |
| Power Tolerance(W) | 0~+5W |
| Temperature Coefficient of Isc(αIsc) | +0.043%/ºC |
| Temperature Coefficient of Voc(βVoc) | -0.26%/ºC |
| Temperature Coefficient of Pmax(γVoc) | -0.36%/ºC |
| STC | Irradiance 1000w/m2, Cell Temperature 25ºC, Air Mass 1.5 |
> High-efficiency MBB PV cell> Uniform color> Anti-PID> Germany standard Cell> Full testGlass
> Antireflective glass> Translucency of normal luminance is increased 2%
> Module efficiency is increased 2%
> Self-clean function
> Service life 25 yearsFrame
> Stock-size
> Silvery and black
> thickness 30/35/40
> stress test.Junction box>Conventional standalone edition and engineering custom edition> Quality diode ensures module running safety> IP67 protection level> Heat dissipation> Long service life
Company Profile
OUR FACTORYOur factory is located in Hefei City Anhui Province.There are about 1000 workers in our company.We establish efficient production team for provide our clients good experience.Packaging & Shipping
